Applications：

     → ODF-, DWDM systems, optical fiber households, all types of fiber-optic communications system, the new sync terminal equipment and subscriber line terminal

Feature：

     → Standard plastic parts, good interchangeability

    → Small size, light weight, suitable for high-density installation

    → RJ-45 push-pull locking structure, reliable and rapid loading and unloading fast

    → Cable diameter：Φ0.9、Φ2.0、Φ3.0

    → Φ1.25Ceramic ferrule, PC, UPC grinding

    → UL can provide fire-Link cable or fiber optic cable Diyanwulu

Specifications：

     Connector                      PC（SM）         UPC（SM）         PC（MM）

     RL                   （dB）     ≥45              ≥50             ≥35

     IL                   （dB）          ≤0.2（Typical），≤0.3（Max）

     Repeatability        （dB）                       ≤0.1

     Durability      （Matings）                       ≥500

     Operating Temperature（℃）                       -25～70

     Tensile Stength       （N）                ≥90（φ3），≥70（φ2）


Alectronics offer Patch cord customize service: all length patch cords with LC FC SC ST .....connectors
With 10 years' experience in Optical field, we can meet all technical requirements.
